Condensation loops curved for manometers

Kondenzační smyčka zahnutá pro manometry

condensing loops are primarily designed to protect the gauge from the effects of medium or high temperature up to +300 °C
two shapes available: curled or curved
pin design - inlet external thread, outlet nut with internal thread
welding design - inlet threaded nut, outlet threaded nut
vertical mounting, outlet side up; in winter operation, the loop must be emptied or filled with antifreeze

Condensation loops for curved manometers
Ordering number	Work pressure bar	Connection		Body material	Standard
Ordering number	Work pressure bar	input	exit	Body material	Standard
KSZC	250	M20 x 1.5 external	M20 x 1.5 nut	steel	AN 137530A
KSZC-N	250	M20 x 1.5 external	M20 x 1.5 nut	stainless steel 1.4571	AN 137530A
KSZP	250	braze	M20 x 1.5 nut	steel	AN 137530B
KSZP-N	250	braze	M20 x 1.5 nut	stainless steel 1.4571	AN 137530B

Condensing loop KSZP-N

Code: KSZP-N

€127,77

(€105,60 excl. VAT)

Condensing loop KSZP

Code: KSZP

€26,36

(€21,79 excl. VAT)

Condensing loop KSZC-N

Code: KSZC-N

€142,82

(€118,03 excl. VAT)

Condensing loop KSZC

()

Code: KSZC

€46,71

(€38,60 excl. VAT)

4 items total

Condensing loop KSZC

Condensing loop KSZC

()

€38,60 excl. VAT

€46,71 / pcs

The condensing loop has M20×1.5 outer and M20×1.5 output nuts. The body of the loop is made of steel.

Code: KSZC

Condensing loop KSZP-N

Condensing loop KSZP-N

€105,60 excl. VAT

€127,77 / pcs

The condensing loop has a follower and an output M20 × 1.5 nut. The body of the loop is stainless steel 1.4571.

Code: KSZP-N

Condensing loop KSZC-N

Condensing loop KSZC-N

€118,03 excl. VAT

€142,82 / pcs

The condensing loop has M20×1.5 outer and M20×1.5 output nuts. The body of the loop is stainless steel 1.4571.

Code: KSZC-N

Condensing loop KSZP

Condensing loop KSZP

€21,79 excl. VAT

€26,36 / pcs

The condensing loop has a follower and an output M20 × 1.5 nut. The body of the loop is made of steel.

Code: KSZP

4 items total
