Steam Hose Steam Profi 165
 |
|
Steam Profi 165 Pressure Hose for steam |
||||||
| Ordering number |
Diameter mm | Pressure bar |
Temperature °C |
Weight kg/m |
Packaging m |
|
| internal | external | |||||
| SP165-10 | 10 | 21 | 7 | -40/+170 | 0,26 | 40 |
| SP165-13 | 13 | 24 | 7 | -40/+170 | 0,45 | 40 |
| SP165-16 | 16 | 28 | 7 | -40/+170 | 0,60 | 40 |
| SP165-20 | 20 | 34 | 7 | -40/+170 | 0,83 | 40 |
| SP165-25 | 25 | 39 | 7 | -40/+170 | 0,90 | 40 |
| SP165-32 | 32 | 46 | 7 | -40/+170 | 1,20 | 40 |
| SP165-40 | 40 | 55 | 7 | -40/+170 | 1,44 | 40 |
| SP165-51 | 51 | 67 | 7 | -40/+170 | 2,40 | 40 |
| SP165-63 | 63 | 81 | 7 | -40/+170 | 2,60 | 40 |
Product sorting
List of products
Pressure hose for transport of pressure saturated steam up to +170 °C, diameter 55/40 mm with red stripe. Reinforcement high-strength textile braid; working temperature -40/+170...
Pressure hose for transport of pressure saturated steam up to +170 °C, diameter 39/25 mm with red stripe. Reinforcement high-strength textile braid; working temperature -40/+170...
Pressure hose for transport of pressure saturated steam up to +170 °C, diameter 24/13 mm with red stripe. Reinforcement high-strength textile braid; working temperature -40/+170...
Pressure hose for transport of pressure saturated steam up to +170 °C, diameter 21/10 mm with red stripe. Reinforcement high-strength textile braid; working temperature -40/+170...
Pressure hose for transport of pressure saturated steam up to +170 °C, diameter 28/16 mm with red stripe. Reinforcement high-strength textile braid; working temperature -40/+170...
Pressure hose for transport of pressure saturated steam up to +170 °C, diameter 81/63 mm with red stripe. Reinforcement high-strength textile braid; working temperature -40/+170...
Pressure hose for transport of pressure saturated steam up to +170 °C, diameter 34/20 mm with red stripe. Reinforcement high-strength textile braid; working temperature -40/+170...
Pressure hose for transport of pressure saturated steam up to +170 °C, diameter 67/51 mm with red stripe. Reinforcement high-strength textile braid; working temperature -40/+170...
Pressure hose for transport of pressure saturated steam up to +170 °C, diameter 46/32 mm with red stripe. Reinforcement high-strength textile braid; working temperature -40/+170...
