RV600 stainless steel check valves
![]() |
|
Stainless steel check valves RV600 for pipeline |
||||||
| Ordering number |
Thread " |
Luminosity DN |
Pressure bar |
Temperature °C |
Material bodies |
Seal |
| RV600-14 | 1/4" | 8 | 40 | up to +180°C | stainless steel DIN 1.4408 | PTFE |
| RV600-38 | 3/8" | 10 | 40 | up to +180°C | stainless steel DIN 1.4408 | PTFE |
| RV600-12 | 1/2" | 15 | 40 | up to +180°C | stainless steel DIN 1.4408 | PTFE |
| RV600-34 | 3/4" | 20 | 40 | up to +180°C | stainless steel DIN 1.4408 | PTFE |
| RV600-10 | 1" | 25 | 40 | up to +180°C | stainless steel DIN 1.4408 | PTFE |
| RV600-54 | 1 1/4" | 32 | 40 | up to +180°C | stainless steel DIN 1.4408 | PTFE |
| RV600-15 | 1 1/2" | 40 | 40 | up to +180°C | stainless steel DIN 1.4408 | PTFE |
| RV600-20 | 2" | 50 | 40 | up to +180°C | stainless steel DIN 1.4408 | PTFE |
Product sorting
List of products
The RV600 non-return valves with G1 1/2" threaded connection ensure the flow of the medium in one direction. Pipe nominal bore DN40. Opening pressure at least 0.8 bar. Made of...
The RV600 non-return valves with G1/2" threaded connection ensure the flow of the medium in one direction. Pipe nominal bore DN15. Opening pressure at least 0.8 bar. Made of...
The RV600 non-return valves with G1/4" threaded connection ensure the flow of the medium in one direction. Pipe nominal bore DN8. Opening pressure at least 0.8 bar. Made of...
The RV600 non-return valves with G3/8" threaded connection ensure the flow of the medium in one direction. Pipe nominal bore DN10. Opening pressure at least 0.8 bar. Made of...
The RV600 non-return valves with G3/4" threaded connection ensure the flow of the medium in one direction. Pipe nominal bore DN20. Opening pressure at least 0.8 bar. Made of...
The RV600 check valves with G1 1/4" threaded connection ensure the flow of the medium in one direction. Pipe nominal bore DN32. Opening pressure at least 0.8 bar. Made of...
The RV600 check valves with G1" threaded connection ensure the flow of the medium in one direction. Pipe nominal bore DN25. Opening pressure at least 0.8 bar. Made of stainless...
The RV600 check valves with G2" threaded connection ensure the flow of the medium in one direction. Pipe nominal bore DN50. Opening pressure at least 0.8 bar. Made of stainless...
