Metal filter FWA38 up to 18 bar - 20 µm - G 3/8" G 3/8" · up to 18 bar · 20 µm filtration · 4100 l/min · 180 × 60 mm
Code: FWA38
Related products
Product detailed description
A metal compressed air filter with a G 3/8" thread and a 20 µm sintered bronze element. It uses centrifugal force to separate dirt, water and oil into a 45 cm³ metal bowl with a sight glass. Flow 4100 l/min.
Specifications
| FWA38 — specifications | |
|---|---|
| Type | Filter |
| Connection | G 3/8" female thread |
| Body size | 2 (body width 60 mm) |
| Inlet pressure | up to 18 bar |
| Flow | 4100 l/min |
| Height × width | 180 × 60 mm |
| Weight | 0.9 kg |
| Filter rating | 20 µm |
| Spare filter element | 20 µm VFK220, finer 5 µm VFK25 |
| Bowl volume | 45 cm³ |
| Condensate drain | semi-automatic |
| Material | zinc alloy, metal bowl with sight glass |
| Working temperature | −10 to +50 °C |
| Medium | compressed air |
What it is for
It belongs at the start of the air treatment, before the regulator and lubricator, and protects tools and machines from water, rust and dirt. The G 3/8" thread is suitable for a workstation with several tools or a small workshop.
The spare filter element is VFK220, the finer one VFK25 and the bowl NFK2. The filter combined with a regulator in one body is FDM38. The same body with a G 1/2" thread is FWA12.
Ventilek’s tip
Filter as close to the consumer as possible. Water also condenses in the piping after the compressor. A filter at the workstation also traps what forms along the way.
Additional parameters
| Category: | Robust metal air treatment units I8 up to 18 bar |
|---|---|
| Version: | Filter |
| Pressure: | 18 bar |
| Dimensions: | 180 × 60 mm |
| Filtering ability: | 20 µm |
| Filter insert: | Replacement insert 20 µm (VFK220) |
| Medium: | Compressed air |
| Vessel volume: | 45 cc |
| Condensate discharge: | Semi-automatic |
| Working temperature: | -10 / 50 °C |
| Flow: | 4,100 l/min |
| Thread: | G 3/8" |
| In stock: | External warehouse |
