Pressure regulator 2", 25,000 l/min, 0.5-16 bar
Code: 417.2124
Related products
Product detailed description
The EWO 417.2124 pressure regulator reduces the pressure of compressed air from the air network – up to 40 bar – to an adjustable 0.5 to 16 bar and keeps it constant even when the pressure fluctuates and air consumption is high. It is a diaphragm regulator with secondary venting: when you reduce the pressure, it releases the excess air from the outlet by itself. Two pressure gauges show the inlet and the outlet pressure.
Size BG 90, connection G 2", flow rate 25,000 l/min. It belongs to the series of large pressure regulators 417 with inlet up to 40 bar.
Specifications
| Parameter | Value |
|---|---|
| Code | 417.2124 |
| Body size | BG 90 |
| Connection | G 2" |
| Control range | 0.5–16 bar |
| Inlet pressure | max. 40 bar (PN 40) |
| Flow rate | 25,000 l/min (inlet 8 bar, outlet 6 bar, pressure drop 1 bar) |
| Flow rate according to the 2022 catalogue | 52,190 l/min (inlet 10 bar, outlet 8 bar, pressure drop 1 bar) |
| Nominal size | DN 50 |
| Inlet pressure influence | < 1 % |
| Design | pilot-operated diaphragm regulator |
| Secondary venting | yes, hysteresis approx. 0.5 bar |
| Pressure gauges | 2× ⌀ 63 mm included: inlet 0–60 bar, outlet 0–25 bar (front or rear mounting) |
| Adjustment | handwheel |
| Mounting position | any, flow in the direction of the arrow |
| Operating temperature | −10 to +90 °C |
| Medium | compressed air, neutral and non-toxic gases |
| Material | cast aluminium body and spring housing, NBR diaphragm and seals |
| Dimensions (width × height) | 160 × 248 mm |
| Weight | 5.83 kg |
Dimensions and flow curve
Manufacturer’s graph for size BG 90 (measured with a G 2" connection): how the outlet pressure drops as the flow rate increases. The lines start at a set pressure of 2 to 10 bar; the inlet pressure is 2 bar higher than the outlet pressure.
Installation and adjustment
- install a high-pressure compressed air filter upstream of the regulator – dirt from the pipework would damage the valve seat
- install the regulator so that the air flows in the direction of the arrow on the body; any mounting position is possible
- the regulator weighs over 5 kg – support the pipework next to it, or fix it to a wall or frame with a mounting bracket
- set the pressure from below: loosen the handwheel to below the required value, then tighten it until the outlet pressure gauge shows the required pressure
Spare parts and accessories
- spare diaphragm: MEMBRANEDR8840
- valve cone: DKDR8840
- spare outlet pressure gauge 0–25 bar: 216
- wall mounting: BW8040
The same regulator in a lockable version: 417.2124A. For lower air consumption with inlet up to 40 bar there are regulators 286, and for inlet up to 60 bar regulators 302.
Additional parameters
| Category: | Air pressure regulators – precision, high-pressure, remote-controlled |
|---|---|
| EAN: | 4030875058932 |
| Pressure: | 40 bar |
| Dimensions: | 160 × 248 mm |
| Weight: | 5,83 kg |
| Flow: | 25,000 l/min |
| Regulatory range: | 0.5 to 16 bar |
| Thread: | G 2" |
| In stock: | External warehouse |
Product rating
Be the first who will post an article to this item!
