Clean Air CLR-1,1-50M dental compressor motor power 1.1 kW, intake 240 l/min, delivery 125 l/min at 5 bar, pressure 8 bar, receiver 50 l, voltage 230/50 V/Hz
Code: CLR-1-1-50M
Related products
Product detailed description
Clean Air CLR · oil-free · 50 lTwice the air reserve of the twenty-five-litre model. The CLR-1,1-50M has the same oil-free pump delivering 125 l/min at 5 bar, but it stands on a fifty-litre receiver — so the motor starts less often. The capacity stays at one to two chairs and the weight is 36 kg.
What the larger receiver brings
The receiver volume does not increase the amount of air produced — delivery does, and that is identical to the twenty-five-litre model. A larger receiver means fewer motor starts and calmer running under intermittent draw, for instance during longer blow-off.
The fifty-litre model is also taller: 850 mm against 670 mm. If the machine stands under a worktop or in a cabinet, measure the height before you order.
Equipment and details
What the CLR-1,1-50M does as standard
- oil-free pump unit — no oil can reach the air
- single-stage compressor, direct drive without belts, 1400 rpm
- 50 l pressure vessel with an epoxy coating inside, working pressure 8 bar
- cyclone water separator; a dryer can be added separately
- open design — 71 dB(A) at one metre
- intake 240 l/min, delivery 125 l/min at 5 bar
- capacity of 1–2 dental chairs per the manufacturer (50 l/min at 5 bar per chair)
- 1.1 kW motor on four anti-vibration mounts, electric motor 230/50 V/Hz — an ordinary socket
- DN 7.2 quick coupling, weight 36 kg, dimensions 450 × 470 × 850 mm
- two-year warranty
Machine detail
The open design leaves the pump, the cooler and the fittings accessible from above. Servicing and checking the drain take minutes, but the machine hides none of its noise.
Where to go if the CLR-1,1-50M does not fit
A smaller receiver is on the CLR-1,1-25M, with a dryer it is the CLR-1,1-50MD. More air comes from the CLR-1,5-50M. The full overview is in the overview of the whole category.
Delivery is the amount of air the machine supplies at 5 bar (FAD per the manufacturer leaflet); intake is the volume drawn in by the pump unit. The noise figure is the sound pressure at one metre from the machine; the sound power level Lwa is in the parameters. The capacity in chairs is calculated on 50 l/min at 5 bar per chair.
Ventilek advises
A bigger receiver will not give you a single litre more air per minute. What you buy is calm: the motor starts less often and the receiver, not the pump, covers the peaks.
Additional parameters
| Category: | Air compressors |
|---|---|
| Warranty: | 3 years |
| Compressor type: | Piston compressor |
| Pressure: | 8 bar |
| Suction power: | 240 l/min |
| Air delivery: | 125 l/min |
| Pressure vessel volume: | 50 L |
| Design of pressure vessel: | Standing |
| Connecting: | Quick coupling DN 7.2 |
| Motor power: | 1.1 kW |
| Mains voltage: | 230/50 V/Hz |
| Speeds: | 1400 rpm |
| Number of cylinders: | 2 |
| Number of grades: | 1 – single-stage compressor |
| Lubrication: | Oil-free |
| Noise: | 91 dB - Lwa, 71 dB - Lwp(4m) |
| Dimensions: | 450 X 470 X 850 mm |
| Weight: | 36 kg |
| Accessories: | Silent blocks, Handle, Quick coupler |
| Engine: | Electric |
| Soundproofed: | No |
| Drive: | Direct |
| Air dryer: | No |
| Retrieved from: | Professional |
| Development: | Stationary |
