Vertical compressor Pro Line B59B-4-200VT, 200 l, 400 V Vertical 200 l tank, 400 V, 4 kW motor, air intake 653 l/min at 1,400 rpm, 11 bar, 97 dB Lwa / 77 dB at 4 m
Code: B59B-4-200VT
Related products
Product detailed description
B59B · vertical 200 l · 653 l/min · 11 bar · 400 VThe only vertical machine with a 200 l tank and the lowest of the B range. The B59B-4-200VT draws in 653 l/min with the cast-iron two-stage B59B pump and a 4 kW motor into a vertical 200 l tank at 11 bar; noise 97 dB Lwa, 77 dB at 4 m. For a tyre shop with two lifts, where the impact wrench and tyre inflation draw air in bursts and the compressor has to stand in a corner under a lower ceiling.
Why 200 l under a cast-iron pump
The B59B pump is the same as on the horizontal machines of the B range: cast-iron cylinders, two stages with an intercooler, 653 l/min at 1,400 rpm. The 200 l tank puts it at a height of 2,050 mm instead of the 2,100 mm of the 270 l version: five centimetres lower, which can be the deciding factor under a low ceiling or under pipework, and on the same 850 × 970 mm footprint. A 200 l reserve is enough where the tools draw air in bursts: an impact wrench at the lift, tyre inflation, blowing off. If you sand or spray for long stretches, take the 270 l.
Equipment and details
What the B59B-4-200VT has from the factory
- two-stage B59B pump with cast-iron cylinders and an intercooler, oil-lubricated, with an oil sight glass; V-belt drive geared down to 1,400 rpm, belt guard
- three-phase 4 kW (5.5 hp) electric motor, 400 V / 50 Hz, thermal overload protection; automatic stop/start pressure switch with a gauge
- intake 653 l/min, pressure 11 bar, aftercooler on the pump outlet
- vertical 200 l tank on three legs with holes for bolting down, condensate drain valve in the bottom; air outlet through a ball valve on the side of the tank (regulator, filter and quick couplings at the workstation)
- noise 97 dB Lwa, 77 dB at 4 m
- AirTube QR code on the tank opens service videos; 2-year warranty (extension to 3 years at extra cost), 10 years on the tank against rusting through
Machine details
Where next if the B59B-4-200VT is not the right fit
The same pump on the taller 270 l tank is the B59B-4-270VT; the same pump on horizontal 90 to 500 l tanks, on castors and on feet, is in the horizontal B59B to B70 range. Two-hundred-litre machines of all brands are grouped together among compressors with a 200 l tank; the other six vertical machines are compared by the overview of the vertical machines. For the lifts there are impact wrenches.
Values apply to a 50 Hz supply. Intake is the amount of air the pump draws in; how much of it reaches the tool depends on the pressure and the tank. Noise is given as the sound power level Lwa and the sound pressure at 4 m from the machine. The dimensions are those of the machine without packaging. A piston compressor works in cycles (topping up the tank and pausing), not continuously.
Ventilek recommends
A tyre shop with two lifts and a low ceiling: 653 l/min from a cast-iron pump, a 200 l reserve for work in bursts and a machine that stands in the corner on less than a square metre.
Additional parameters
| Category: | Air compressors |
|---|---|
| Warranty: | 2 years |
| EAN: | 8024900537529 |
| Compressor type: | Piston compressor |
| Pressure: | 11 bars |
| Suction power: | 653 l/min |
| Air delivery: | 503 l/min |
| Pressure vessel volume: | 200 L |
| Design of pressure vessel: | Standing |
| Connecting: | Ball valve 1/2" |
| Motor power: | 4.0 kW |
| Mains voltage: | 400/50 V/Hz |
| Speeds: | 1400 rpm |
| Number of cylinders: | 2 |
| Number of grades: | 2 – two-stage compressor |
| Lubrication: | Oleic |
| Noise: | 97 dB - Lwa, 77 dB - Lwp(4m) |
| Weight: | 205 kg |
| Accessories: | Ball cock |
| Engine: | Electric |
| Soundproofed: | No |
| Drive: | V-belts |
| Air dryer: | No |
| Retrieved from: | Professional |
| Development: | Stationary |
| Dimensions: | 850 × 970 × 2 050 mm |
