Vertical compressor Pro Line B59B-4-270VT, 270 l, 400 V Vertical 270 l tank, 400 V, 4 kW motor, air intake 653 l/min at 1,400 rpm, 11 bar, 97 dB Lwa / 77 dB at 4 m
Code: B59B-4-270VT
Related products
Product detailed description
B59B · vertical 270 l · 653 l/min · 11 bar · 400 VThe cast-iron B59B pump on a vertical 270 l tank — the machine you see in the detail pictures of the whole range. The B59B-4-270VT draws in 653 l/min with the two-stage B59B pump and a 4 kW motor at 1,400 rpm and fills 270 l to 11 bar; 97 dB Lwa and 77 dB at 4 m. For a tyre shop, body shop or paint shop where the air is drawn for long stretches and the compressor has to stand in a corner.
Why the B59B instead of the A49B on the same tank
Both pumps have a 4 kW motor and both fill 270 l to 11 bar; the B59B gives 653 l/min instead of 595 and has cylinders cast in iron — for long runs under load with a sander, a gun or sandblasting in bursts. You pay for it in height and footprint: the B range machine stands on 850 × 970 mm and is 2,100 mm tall, the A49BP-4-270VT on 830 × 644 mm and 1,714 mm. On the plate above the tank, next to the pump, sit the pressure switch, the rating plate and the noise sticker; the air leaves through a ball valve on the side of the tank, the condensate through a valve in the bottom.
Equipment and details
What the B59B-4-270VT has from the factory
- two-stage B59B pump with cast-iron cylinders and an intercooler, oil-lubricated, with an oil sight glass; V-belt drive geared down to 1,400 rpm, belt guard
- three-phase 4 kW (5.5 hp) electric motor, 400 V / 50 Hz, thermal overload protection; automatic stop/start pressure switch with a gauge
- air intake 653 l/min, pressure 11 bar, aftercooler on the pump outlet
- vertical 270 l tank on three legs with holes for bolting down, condensate drain valve in the bottom; air outlet through a ball valve on the side of the tank (regulator, filter and quick couplings at the workstation)
- noise 97 dB Lwa, 77 dB at 4 m
- AirTube QR code on the tank opens service videos; 2-year warranty (extension to 3 years at extra cost), 10 years on the tank against rusting through
Machine details
Where next if the B59B-4-270VT is not the right fit
The same pump on the lower 200 l tank is the B59B-4-200VT; more displacement from the same footprint, with the B60 pump, comes from the B60-5.5-270VT. The same 653 l/min and 270 l on a horizontal tank come from the horizontal B59B-4-270FT on feet. When the pump is due for replacement after years of service, we carry it separately as the B59B compressor pump; the comparison with the other six is in the overview of all seven vertical machines.
Values apply to a 50 Hz supply. Air intake is the amount of air the pump draws in; how much of it reaches the tool depends on the pressure and the tank. Noise is given as the sound power level Lwa and the sound pressure at 4 m from the machine. The dimensions are those of the machine without packaging. A piston compressor works in cycles (topping up the tank and pausing), not continuously.
Ventilek advises
A vertical 270 for a tyre shop or body shop: a cast-iron pump, 653 l/min and a machine that takes up a corner instead of a wall.
Additional parameters
| Category: | Air compressors |
|---|---|
| Warranty: | 2 years |
| EAN: | 8024900524499 |
| Compressor type: | Piston compressor |
| Pressure: | 11 bars |
| Suction power: | 653 l/min |
| Air delivery: | 503 l/min |
| Pressure vessel volume: | 270 L |
| Design of pressure vessel: | Standing |
| Connecting: | Ball valve 1/2" |
| Motor power: | 4.0 kW |
| Mains voltage: | 400/50 V/Hz |
| Speeds: | 1400 rpm |
| Number of cylinders: | 2 |
| Number of grades: | 2 – two-stage compressor |
| Lubrication: | Oleic |
| Noise: | 97 dB - Lwa, 77 dB - Lwp(4m) |
| Weight: | 210 kg |
| Accessories: | Ball cock |
| Engine: | Electric |
| Soundproofed: | No |
| Drive: | V-belts |
| Air dryer: | No |
| Retrieved from: | Professional |
| Development: | Stationary |
| Dimensions: | 850 × 970 × 2 100 mm |
