Compressor Pro Line Expert A49BP-4-200CT, 200 l, 400 V Expert, motor power 4 kW, air intake 595 l/min, pressure 11 bar, air receiver 200 l, voltage 400/50 V/Hz, 97 dB Lwa / 77 dB at 4 m
Code: A49BP-4-200CT
Related products
Product detailed description
Expert · 200 l · 400 V · 595 l/min · 11 barThe biggest motor in the range on a 200 l tank. Four kilowatts on 400 V drive the two-stage A49B pump at 1,400 rpm on the A49BP-4-200CT — 595 l/min, 11 bar, 200 l, 125 kg. For a paint shop or a garage where the gun or the sander never lets go of the trigger and the machine should still be movable.
Why 4 kW with 200 l
The most air the A49B pump gives — 595 l/min at 1,400 rpm in two stages — on a tank that can still be wheeled: 125 kg, two front castors with brakes and a handle. A spray gun or a sander running non-stop draws from 200 l at 11 bar and the pump keeps pace, so the motor does not start over and over. The filter-regulator with two quick couplings on the tank neck gives two people a hose each and catches the condensate. If you want the biggest reserve with this motor, take the 270 l. The biggest motor also brings the highest noise in the range: 97 dB Lwa, 77 dB at 4 m.
Equipment and details
What the A49BP-4-200CT has from the factory
- two-stage twin-cylinder oil-lubricated A49B pump with an oil sight glass, V-belt drive under a moulded belt guard, 1,400 rpm
- three-phase 4 kW (5.5 hp) electric motor, 400 V / 50 Hz, thermal overload protection; automatic stop/start pressure switch
- air intake 595 l/min, 11 bar, aftercooler on the pump outlet
- horizontal 200 l tank with a ball valve for draining condensate
- filter-regulator with a gauge and two DN 7.2 quick couplings on the tank neck, two gauges (tank and outlet)
- two front swivel castors with brakes, two rear wheels, closed handle with a rubber grip
- noise 97 dB Lwa, 77 dB at 4 m
- AirTube QR code on the tank opens service videos; 2-year warranty, 10 years on the tank against rusting through
Machine details
Where next if the A49BP-4-200CT is not the right fit
The same motor with the biggest tank is the A49BP-4-270CT; the same tank with a 3 kW motor is the A49BP-3-200CT. Both four-kilowatt Experts and the Extensive are compared on the A49B range page; four-kilowatt machines of all brands are compared among compressors with a 4 kW motor. Downstream of the filter-regulator goes a spray gun.
Values apply to a 50 Hz supply. Air intake is the amount of air the pump draws in; how much of it reaches the tool depends on the pressure and the tank. Noise is given as the sound power level Lwa and the sound pressure at 4 m from the machine. A piston compressor works in cycles (topping up the tank and pausing), not continuously.
Ventilek advises
Four kilowatts on 200 l: the most air in the range on a tank you can still wheel about.
Additional parameters
| Category: | Air compressors |
|---|---|
| Warranty: | 2 years |
| Compressor type: | Piston compressor |
| Pressure: | 11 bars |
| Suction power: | 595 l/min |
| Air delivery: | 458 l/min |
| Pressure vessel volume: | 200 L |
| Design of pressure vessel: | Lying down |
| Connecting: | Quick coupling DN 7.2 |
| Motor power: | 4.0 kW |
| Mains voltage: | 400/50 V/Hz |
| Speeds: | 1400 rpm |
| Number of cylinders: | 2 |
| Number of grades: | 2 – two-stage compressor |
| Lubrication: | Oleic |
| Noise: | 97 dB - Lwa, 77 dB - Lwp(4m) |
| Weight: | 125 kg |
| Accessories: | Pressure regulator, Wheels, Handle, Quick coupler, Filtration |
| Engine: | Electric |
| Soundproofed: | No |
| Drive: | V-belts |
| Air dryer: | No |
| Retrieved from: | Professional |
| Development: | Mobile |
| In stock: | External warehouse |
| Dimensions: | 1 422 x 572 x 1 042 mm |
