Side manometer 0/160 bar - 63 mm - M12*1.5
Free shipping
For purchases over 5,000 CZK
We guarantee
Extended warranty and service
Discount voucher
For every purchase
Return of goods within 30 days
Completely at our expense
Related products
–5 %
Manometer cover GOMB-63
The diameter of the cover is 63 mm. It is suitable for applications with...
Pressure gauge connection socket PTN-M12M12L
The connection is equipped with two internal threads M12 × 1.5 and M12 × 1...
Sealing ring TP-M12
Sealing ring made of aluminium for thread M12 × 1.5; G 1/4".
Basic plastic manometer MS05-20
- Materials used : plastic body, copper alloy measuring element and pointer, acrylic windscreen
- Basic design of pressure gauges with side connection, designed for pressure measurement of non-aggressive media with lower requirements for mechanical resistance of the instrument
- Manometers with diameter 63 mm in plastic version with thread M12*1,5
- Accuracy class 2.5% with temperature range -40/+60
Technical parameters
| Category: | Plastic manometers MS63M |
|---|---|
| Version: | Plastic manometers |
| Connecting: | party |
| Windscreen: | Acrylic |
| Material: | Plastic |
| Medium: | Air, Water |
| Measuring member: | Brass |
| Average: | 63 mm |
| Scope: | 0 to 160 bar |
| Temperature: | -40/+60°C |
| Accuracy class: | 2,5 % |
| Thread: | M12 x 1.5 |
| Glycerin damping: | No |
