Condensation dryer MDX 18000

mdx 4 susicka vzduchu kondenzacni kondenzat kompresor
FREEFREE Shipping
We currently do not have a guaranteed price for this product, so it is only available on request.
Out of Sale
Set up a watchdog
We deliver to:
16.10.2025
Delivery offer
The item has been sold out…

The MDX18000 series condensation dryer with a maximum flow rate of 18,000 l/min and inlet pressure up to 14 bar is used to remove condensate and moisture from compressed air produced by a compressor to a dew point of 4°C using refrigerant R410A. Moisture in the air is precipitated after cooling below the dew point, they are equipped with automatic condensate discharge ECD. Maximum inlet medium temperature: 55 °C.

Detailed information

Code: MDX18000
Free shipping
Free shipping
For purchases over 5,000 CZK
We guarantee
We guarantee
Extended warranty and service
Discount voucher
Discount voucher
For every purchase
Return of goods within 30 days
Return of goods within 30 days
Completely at our expense

MARK MDX18000 Condensing Compressed Air Dryer

  • condensation dryers for removing moisture from compressed air
  • pressure dew point +4 ±1°C, automatic discharge by lossless electronic LogiDrain
  • digital control unit with dew point indication, push-button switching on the front side
  • modern and environmentally friendly refrigerants for reduced power consumption and very low GWP values
  • working pressure: 16 bar (MDX400-1800); 14 bar (MDX2400-84000)
  • maximum inlet media temperature: 55 °C (MDX400-7700); 60 °C (MDX10000-84000)
  • operating temperature in the installation room: +5 °C / +43 °C (MDX400-7700); +5 °C / +46 °C (MDX10000-84000)
  • coolant: MDX400-3000 = R513A, MDX3600-35000 = R410A, MDX45000-84000 = R452A
  • designed primarily for industrial use and workshop environments
  • flow measurement reference conditions: ambient temperature +25 °C, medium temperature +35 °C, working pressure 7 bar, dew point +4 °C ±1 °C.
  • for conditions other than the reference, a correction factor must be used for the calculation - please contact our company

Kondenzační sušičky MDX

Výhody kondenzačních sušiček stlačeného vzduchu

CHYTRÉ ŘEŠENÍ PRO VYSOKOU SPOLEHLIVOST

Funkční principy sušení stlačeného vzduchu z kompresoru kondenzační sušičkou

Technická data a korekční faktory

Product is included in the following categories: Air conditioning Air dryers

Technical parameters

Category: Compressed Air Moisture Removal Air Dryers
Pressure: 14 bar (14 atm, 203 PSI, 1,4 MPa)
Connecting: 2 1/2"
Motor power: 2770 W
Mains voltage: 230/50 V/Hz
Dimensions: 805 x 1070 x 962 mm
Flow: 18 l/min (1,08 m³/h, 0,6354 CFM)
Equipment:: Control unit LED display, Automatic draining of condensate
Refrigerant: Refrigerant R410a
Pressure dew point: +4 °C
Dryer type: Condensation dryer
The item has been sold out…
